Shut It® BadAss™ Powder Coat Face Mount Bolt-On

Designed for gates where welding is not an option
• Opens to 180°
• Achieve gate gaps as small as 13mm (1/2")
• Horizontally adjustable to 13mm (1/2")

• Components individually powder coated for full coverage
• Matt black zinc for long-lasting rust and corrosion protection
• Hard-wearing, UV rated finish
• Maintenance-free, sealed radial ball-bearings
• Horizontally adjustable for perfect installations
• Tested to over 1 Million open/close cycles
• Highest gate weight rating in the industry
• Ideal for both aluminium and steel gates
Load rating per gate: 900kg (2,000 lb)
Maximum gate weight: 500kg (1,100 lb)
The Bolt-On BadAss was designed to be used on gates where welding the hinges to the gate and the end post is not an option. Due to SHUT IT’s unique bushing design The Bolt-On BadAsses, like all other SHUT IT gate hinges, produces near frictionless movement with maintenance free usage.

Brand	Shut It® BadAss
Product Code	CI3720B
Gate Application	Pedestrian Gate, Driveway Gate - Double, Driveway Gate - Single, Pet Gate, Playground Gate, Public/Commercial Gate, Automated/Electric Gate, Security Gate, Privacy Gate
Gate Type	Non Self-Closing
Gate Material	Steel/Ornamental Iron/Aluminium
Approx Gate Size	2m H x 3m W - (7ft x 10ft)
Gate Frame/Post Shape	Square-to-Square
Min Post Size	38mm+ (1½")
Ideal Gate Gap	13-25mm (½-1")
Fixing Method	Bolt-On
Colour/Finish	Matt Black Zinc
